Key Features

  • Tamper switch
  • Fireproof ABS housing
  • Automatic temperature compensation
  • Pulse count optional
  • Alarm output N.C./ N.O. optional
Wired PIR Motion Detector

SECURESURVEIL SV-101PIR Wired Wide Angle PIR Motion Detector

SV-101PIR

In stock
Regular price $15.00 CAD Sale price $15.00 CAD Regular price $18.00 CAD
Sale 16.67% $3.00 CAD (16.67%)
Shipping calculated at checkout.

Key Features

  • Tamper switch
  • Fireproof ABS housing
  • Automatic temperature compensation
  • Pulse count optional
  • Alarm output N.C./ N.O. optional
Easy Installing

Quick and hassle-free setup, with user-friendly manuals and plug-and-play support

Risk-Free Returns

Enjoy peace of mind with our 30-day return policy.

One-Year Warranty

All purchases come with a 1-year warranty, except for hard disks.

No Monthly Fees

Own your alarm system with no contracts, Pay once, protect forever.

Easy Installing

Quick and hassle-free setup, with user-friendly manuals and plug-and-play support

Risk-Free Returns

Enjoy peace of mind with our 30-day return policy.

One-Year Warranty

All purchases come with a 1-year warranty, except for hard disks.

No Monthly Fees

Own your alarm system with no contracts, Pay once, protect forever.

Wired Wide Angle PIR Motion Detector

Overview

is a wide angle passive infrared detector, exquisite design, easy installation. Fit for the locations of the balcony, window, door, corridors, etc. Imported high-end infrared sensor, SMT chip technology, anti-EMI & anti-RFI design, temperature compensation, pulse count, LED switch, etc. selectable functions, can be integrated with wired alarm host.


Specifications

  • key specifications
    • General

      Working Voltage:                      9V-16V
      Standby Current:                       18mA
      Alarm Current:                             20mA
      Wide Detector Angle:           110° (10.6mX10.6m)
      Detection Distance:                12m (25℃)
      Detection Speed:                       0.2-7m/s
      Sensitivity: Level 2                    adjustable
      Installation Way:                        Wall Hanging
      Installation Height:                   1.1m-3.1m Adjustable
      Alarm output:                                NC
      LED indicator light:                     ON/OFF optional
      Operating temperature:       -10°C to 50°C
      Item Size:                                  108*65*52mm(L*W*H)
      Item Weight:                                  72g

    • Packaging Info

      Dimensions (mm)                  132 X 80 X 50
      Weight (g)                                   95

    • sku SV-101PIR

Include in the box


Wired Wide Angle PIR Detector


User Guide
